Product Description

SD5 SD8 Series Monoblock Directional Control Hydraulic Valve

SD5 Series Monoblock Directional Control Valve

Optional carry-over port (only for parallel or tandem circuit).


Diameter 16 mm -0.63 in interchangeable spools.


A wide variety of service port valve options.


Actuation is manual, pneumatic, electro--pneumatic, hydraulic, electro--hydraulic, with solenoid and remote with flexible cables


spool control kits.


STANDARD THREAD 3/8"

Type
E(mm)
F(mm)
Weight (kg)
SD5/1-P
100.5
73
3.75
SD5/2-P
137.5
110
5.45
SD5/3-P
174.5
147
7.2
SD5/4-P
211.5
184
8.8
SD5/5-P
248.5
221
10.5
SD5/6-P
285.5
258
12.2
SD5/7-P
322.5
395
13.7
