Product Description


3 lever P80 manual control with pneumatic control kits 3P80 80L/MIN Hydraulic Control Valve

p80 Series hydraulic distributor P80 is used for switching on/off and directing the working fluid between head flow generators (hydraulic pumps), head flow consumers (hydraulic cylinders, motors, etc.), and the tank. It is manufactured with up to 6 plungers with parallel or serial distribution.


Ambient temperature -40°C~+60°C

Viscosity 12 ~800 mm²/s

Fluid temperature -15°C~+80C

Filtration 10 to NAS 1638

Max operating pressure 315 bar

Max back pressure 50 bar

Nominal flow rate 80 l/min

Leakage(A,B-T) 18cm³/min at 120bar

Spool stroke ±7 mm

Actuating force < 220 N

Modification/ Spools 1 to 6

P80 1.png
