Rexroth A10VNO Series Axial Piston Pump,A10VNO28/45/63/85 Hydraulic Pump

Rexroth A10VNO Series Axial Piston Pump,A10VNO28/45/63/85 Hydraulic Pump

Product Description

Rexroth A10VNO Series Axial Piston Pump,A10VNO28/45/63/85 Hydraulic Pump

– Rexroth A10VNO swash plate axial piston variable displacement pump for open circuit hydrostatic drives

– Flow rate is proportional to drive speed and displacement. Flow rate can be varied infinitely by adjusting the swash plate.

– High power-to-weight ratio and small dimensions

– Low noise level

– A10VNO hydraulic piston pump allows continuous pressure of 210 bar

– Drive shaft can withstand axial and radial loads

– Pressure and flow control

– Short response times

– Proven A10 technology

– Variable axial A10VNO piston pump with extremely small installation dimensions

– Cost-effective alternative to fixed displacement pumps

– Cost-optimized design

Size				A10VNO 28	A10VNO 45	A10VNO 63	A10VNO 85
Displacement		V g max	cm3	28	45	63	85
Speed2) max. at V g max		n 1) 0 max 1	min-1	3200	2900	2700	2700
Flow at n 0 max		qV0 max 11)	L/min	90	131	170	230
Power at n 0 max	Δp = 210 bar	P0 max 11)	kW	31	46	59	80
Torque at V g max	Δp = 210 bar	T max	Nm	94	150	210	284
Torsional stiffness Wellenende R		c	Nm/rad	14800	26500	40500	69400
Moment of inertia rotary group		J TW	kgm2	0,001	0,002	0,004	0,006
Angular acceleration, max.2)		a	rad/s2	6800	4900	3500	2500
Case volume		V	L	0,25	0,3	0,5	0,8
Weight (with press. control)		m	kg	11,5	14	18	22
