Eaton VIS40 Hydraulic Orbital Motor,VIS40 Hydraulic Motor

1.The VIS 40 motor is very similar in size to the VIS 30, but offers greater torque capacity due to its enhanced drivetrain

 strength. Pressure capabilities include a continuous pressure rating of 310 bar (4500 PSI), intermittent pressure of 345

 bar (5000 PSI), and peak pressure of 380 bar (5500 PSI). In terms of torque, the VIS 40 offers 2531 Nm (22400 lb-in)

continuous torque and 3165 Nm (28000 lb-in) intermittent torque.

2.The VIS 40 motor has a maximum continuous output torque of 2531 Nm (22400 lb-in) and is available in displacements

ranging from 505cc to 940cc per revolution. The motor can operate at speeds up to 151 LPM (40 GPM) and has a

maximum pressure capability of 310 bar (4500 PSI).

3.The Eaton VIS 40 motor features patented VIS technology with high-strength gear rollers, optimized drive geometry,

and a two-piece preload balance plate for improved starting efficiency, reduced leakage, and increased backpressure

capability.

4.The Eaton VIS 40 hydraulic motor offers a variety of configuration options, including dual speed selection, braking

capabilities, and case flow options for closed and open loop applications.
