Product Description


SD180 Directional Control Valve, SD180 Hydraulic Sectional Valve for tractors

1. Simple, compact and heavy duty designed sectional valve from 1 to 12 sections for open and closed center hydraulic       systems.

2. Fitted with a main pressure relief valve and a load check valve on every working section

3. Available with parallel, tandem or series circuit.

4.  Optional carry-over port.

5.  A wide range of antishock+anticavitation port valves.

6.  Intermediate sections for several types of circuit.

7.  Available manual, pneumatic, electrohydraulic, proportional hydraulic, spool control kits.

8.  Diameter 20 mm (0.79 in) interchangeable spools.


Nom. Pressure
（MPa）
Max.Pressure
（MPa）
Nom.Flow rate
（L/min）
Back Pressure
（MPa）
Hydraulic Oil
Tem.rang
（℃）
Visc.rang
（mm2/S）
Filtrating Accuracy
（μm）
16
31.5
160
≤1
-20～+80
10～400
≤10


sd180 1.png
