Product Description


Kawasaki K3V63 K3V112 K3V140 K3V280 Hydraulic Piston Pump For Excavator

Kawasaki K3V series hydraulic piston pumps are available for excavator, K3V63, K3V112, K3V140 and K3V280 Pump

1.High power density and compact design

The Kawasaki K3V piston pump adopts a semi-logarithmic swash plate design, which achieves a lighter and more

compact structure while providing higher pressure levels and power density (ratio of output power to mass). In

particular, the dual pump tandem configuration eliminates the power distributor, improves transmission efficiency

and reduces weight.


2.High efficiency and self-priming capability

The spherical valve plate and improved hydraulic balance design ensure stable cylinder rotation and efficient

 operation even under low pressure and low speed conditions. This design of the Kawasaki K3V piston pump

is particularly suitable for systems that require stable flow and pressure.







Size63112140280
Displacement                                             (cm3)63112140280
Pressure (MPa)1  Rated34.3
Peak39.2
Speed


(min-1)

2 Max. for self priming2,6502,3602,150(2,000)
3 Max.3,2502,7002,5002,000
Max. input torque of tandem pump           (N·m)3435881,1201,950
Max. input torque of attached gear pump with PTO  (N·m)125294
