Product Description


KRACHT KF315 KF400 KF500 KF630RF1 Hydraulic Gear Pump,KRACHT KF315 Pump

The central element in numerous technical processes is the metering of liquids. PU components, plasticisers,

resins, adhesives,lacquers and paints are just a few of the important liquids with a broad application spectrum.

 The accuracy, uniformity and reproducibility with which these liquids can be processed is also decisive for the

quality of the final product. Ideal for these applications is the KRACHT gear pump KF1/4…KF1/24 coated. The

 KF1/4…KF1/24 coated are external gear pumps with a discharge volume of 4 cm3/rev to 24 cm3/rev.


All gear parts and bearing bushes are protected against wear and corrosion by means of a special coating, so

that also filled media up to a certain particle size and hardness of the fillers can be pumped. Guide values in

 this respect are a maximum particle size of 30 µm and a Mohs hardness of 6. The double rotary shaft seals

enable operation with sealing liquid (quench) to prevent hardening or crystallising of the pumped medium.

On request the KF 1/4…KF1/24 coated can be supplied with a magnetic drive.
