Product Description


MCR3, MCR5, MCR10 Rexroth Hydraulic Radial Piston Motor,MCR3, MCR5, MCR10 Hydraulic Motor

The Rexroth MCR piston motor adopts a compact and sturdy structural design to ensure stable operation under harsh

working conditions. It also has high volumetric efficiency and mechanical efficiency, significantly improving system

performance.

Its rear shell mounting and hub flange design with hub studs provide flexible installation methods.


Rexroth MCR piston motors are known for their high reliability and low maintenance requirements. They can run

smoothly even at extremely low speeds and maintain low noise characteristics, meeting the needs of quiet working

environments.


It supports bidirectional operation and is equipped with sealed tapered roller bearings that can withstand high radial

forces on the drive shaft and has a free-wheeling function to further improve adaptability.


A variety of optional configurations are available, including multi-disk holding brakes, dynamic drum or disc brakes,

bi-directional two-speed operation, integrated flush valves and speed sensors to meet the precise needs of different

applications.
